Drupal service container deep dive part 1: tags, compiler passes, service providers and autoconfiguration

The evolution of Drupal core has increasingly embraced modern PHP standards and robust object-oriented programming (OOP) principles, driven largely by its integration of Symfony components. Central to this modernization is the Service Container, which acts as the core registry responsible for service instantiation, dependency resolution, and lifecycle management.

A service is inherently a specialized, reusable, and stateless object designed to perform a single, well-defined task, such as ConfigFactory for configuration access or EntityTypeManager for entity access.

The philosophy underpinning service usage is the promotion of loose coupling and adherence to the Dependency Inversion Principle (DIP). A class using a service should request it from the container rather than manually instantiating it with the new keyword. This arrangement enables developers to swap implementations without altering consuming code.

In this series of articles, we will explore the Drupal service container in depth, focusing on its features, capabilities, and best practices for leveraging it effectively in Drupal module development.

• Part 1 will cover service tags, compiler passes, service providers, and autoconfiguration, laying the groundwork for understanding how services are defined and managed within the container.
• Part 2 will delve into aliases, autowiring, and name arguments, demonstrating how to resolve and inject dependencies based on type hints, reducing boilerplate code and enhancing maintainability.
• Part 3 will cover service collectors, which aggregate multiple services into a single service for streamlined access.
• Part 4 will explore factories, which provide a mechanism for creating services with complex initialization logic.
• Part 5 will discuss backend overrides, enabling developers to customize service implementations for specific environments or use cases.
• Part 6 will examine advanced features of the Drupal service container, such as service decoration and lazy loading.

Anatomy of a Drupal service

A Drupal service is defined within a module’s MODULE.services.yml file:

# in modules/contrib/webprofiler/webprofiler.services.yml
services:
    webprofiler.matcher.exclude_path:
        class: Drupal\webprofiler\RequestMatcher\WebprofilerRequestMatcher
        arguments: ['@path.matcher', '@config.factory', 'exclude_paths']

# in core/core.services.yml
services:
    path.matcher:
        class: Drupal\Core\Path\PathMatcher
        arguments: ['@config.factory', '@current_route_match']
    config.factory:
        class: Drupal\Core\Config\ConfigFactory
    current_route_match:
        class: Drupal\Core\Routing\CurrentRouteMatch
        arguments: ['@request_stack']
    request_stack:
        class: Symfony\Component\HttpFoundation\RequestStack

When code asks for the webprofiler.matcher.exclude_path service, the Drupal service container first builds all the required services and finally builds an instance of the WebprofilerRequestMatcher class by injecting all the dependencies in the __construct method:

namespace Drupal\webprofiler\RequestMatcher;

use Drupal\Core\Config\ConfigFactoryInterface;
use Drupal\Core\Path\PathMatcherInterface;
use Symfony\Component\HttpFoundation\RequestMatcherInterface;

class WebprofilerRequestMatcher implements RequestMatcherInterface {

  public function __construct(
    private readonly PathMatcherInterface $pathMatcher,
    private readonly ConfigFactoryInterface $configFactory,
    private readonly string $configuration,
  ) {...}
}

The resolution graph looks like this:

  graph TD
    B[current_route_match] --> A[request_stack];
    D[path.matcher] --> C[config.factory];
    D --> B;
    E[webprofiler.matcher.exclude_path] --> D;
    E --> C;

So Drupal first builds the request_stack service, then the current_route_match service (which depends on request_stack), then the config.factory service, then the path.matcher service (which depends on both config.factory and current_route_match), and finally the webprofiler.matcher.exclude_path service (which depends on both path.matcher and config.factory).

Notice that the third argument of the webprofiler.matcher.exclude_path service is a string (exclude_paths). The service container supports injecting scalar values like strings, integers, and booleans as arguments to services:

• @ prefix indicates a service reference.
• % prefix indicates a parameter reference.
• @? indicates an optional service reference.
• No prefix indicates a literal value.

parameters:
  param1: 'some string'

services:
  some_service1:
    class: Some\Class\Name1

  some_service2:
    class: Some\Class\Name2
    arguments: ['@some_service1', '%param1%', 42, true, 'another string', '@?some_service3']

and the code for some_service2 would look like this:

namespace Some\Class;

class Name2 {
  public function __construct(
    private readonly Name1 $someService1,
    private readonly string $param1,
    private readonly int $param2,
    private readonly bool $param3,
    private readonly string $param4,
    private readonly ?Name3 $someService3 = null,
  ) {...}
}

Differences between Drupal and Symfony service containers

The Drupal service container is built on top of the Symfony service container, inheriting many of its features and capabilities. However the Drupal modular architecture and specific requirements have led to several changes. On the other hand, Drupal doesn’t use the Symfony Config component for service configuration, instead relying on its own YAML-based service definition files.

At the end both YAML loading and service container dumping have been heavily customized in Drupal to fit its architecture and performance needs, resulting in a service container that is optimized for Drupal’s unique use cases but not fully equivalent to the standard Symfony service container.

Those differences can lead to some confusion when reading Symfony documentation, as some features may not be available or behave differently in Drupal. This article series aims to clarify those differences and provide a comprehensive understanding of the Drupal service container.

Service Tags

Service tags are metadata annotations that can be applied to service definitions within the Drupal service container. They provide a way to categorize and group services based on their functionality or purpose.

services:
  webprofiler.database:
    class: Drupal\webprofiler\DataCollector\DatabaseDataCollector
    arguments: ['@database', '@config.factory']
    tags:
      - {
          name: data_collector,
          template: '@webprofiler/Collector/database.html.twig',
          id: 'database',
          label: 'Database',
          priority: 750,
        }

A tag has a mandatory name attribute and can have any number of additional attributes. In the example above, the webprofiler.database service is tagged with the data_collector tag, along with several additional attributes such as template, id, label, and priority.

Tags on their own don’t actually alter the functionality of a service in any way. They are primarily used to identify services for special processing during the container compilation phase, often through the use of compiler passes.

Compiler Passes

Compiler passes are a mechanism that allows developers to modify the service container during its compilation phase. They provide a way to programmatically alter service definitions, add or remove services, and manipulate tags before the container is fully built and dumped to the cache

Compiler passes are particularly useful for implementing complex service registration logic, such as dynamically adding services based on configuration or other runtime conditions. They are executed in a specific order during the container compilation process, allowing for fine-grained control over the final service definitions.

namespace Drupal\webprofiler\Compiler;

use Symfony\Component\DependencyInjection\Compiler\CompilerPassInterface;
use Symfony\Component\DependencyInjection\ContainerBuilder;

final class ProfilerPass implements CompilerPassInterface {

  public function process(ContainerBuilder $c): void {

    foreach ($c->findTaggedServiceIds('data_collector', TRUE) as $id => $attributes) {
        ...
    }
  }
}

A shown in the example above, the ProfilerPass class implements the CompilerPassInterface and defines a process method that is called during the container compilation phase. Within this method, the findTaggedServiceIds function is used to retrieve all services tagged with data_collector, allowing for custom processing of those services. The process method can modify the service definitions as needed, such as adding additional arguments, changing class names, or even removing services from the container.

A compiler pass must be registered with the container in order to be executed during the compilation phase. This is typically done within a module’s service provider class.

Service Providers

Service providers are classes that encapsulate the logic for dynamically registering or altering services within the Drupal service container. Service providers typically extend the ServiceProviderBase class and re-define the register or alter methods to add or modify service definitions.

namespace Drupal\webprofiler;

use Drupal\Core\DependencyInjection\ContainerBuilder;
use Drupal\Core\DependencyInjection\ServiceProviderBase;

class WebprofilerServiceProvider extends ServiceProviderBase {

  public function register(ContainerBuilder $container): void {
    [...]
  }

  public function alter(ContainerBuilder $container): void {
     [...]
  }
}

The name and the namespace of the service provider class must follow a specific convention: it should be named ModuleServiceProvider and be located in the root namespace of the module. For example, the service provider for the webprofiler module is named WebprofilerServiceProvider and is located in the Drupal\webprofiler namespace. If the module name contains underscores, they should be removed and the following letter capitalized (e.g., search_api becomes SearchApiServiceProvider). Core has its own service provider named CoreServiceProvider located in the Drupal\Core namespace.

The register method can be used to add compiler passes to the container:

namespace Drupal\webprofiler;

use Drupal\Core\DependencyInjection\ContainerBuilder;
use Drupal\Core\DependencyInjection\ServiceProviderBase;

class WebprofilerServiceProvider extends ServiceProviderBase {

  public function register(ContainerBuilder $container): void {
    $container->addCompilerPass(new ProfilerPass());
  }
}

If the order of execution of compiler passes matters, you can specify the pass type and priority when adding the compiler pass:

$container->addCompilerPass(
  pass: new ProfilerPass(),
  type: PassConfig::TYPE_BEFORE_OPTIMIZATION,
  priority: 10
);

Values for type can be:

• PassConfig::TYPE_BEFORE_OPTIMIZATION
• PassConfig::TYPE_OPTIMIZE
• PassConfig::TYPE_BEFORE_REMOVING
• PassConfig::TYPE_REMOVE
• PassConfig::TYPE_AFTER_REMOVING

This diagram that illustrates when compiler passes are executed during the Symfony service container compilation process:

  graph TD
    A[Container Compilation Start] --> B[Load Service Definitions]
    B --> C[Register Service Providers]
    C --> D[TYPE_BEFORE_OPTIMIZATION<br/>Priority: High to Low]
    D --> E[TYPE_OPTIMIZE<br/>Priority: High to Low]
    E --> F[TYPE_BEFORE_REMOVING<br/>Priority: High to Low]
    F --> G[TYPE_REMOVE<br/>Priority: High to Low]
    G --> H[TYPE_AFTER_REMOVING<br/>Priority: High to Low]
    H --> I[Final Container Dump]

    D1[Custom Compiler Passes<br/>e.g., ProfilerPass] --> D
    D2[Resolve Class Parameters] --> D
    D3[Resolve Invalid References] --> D

    E1[Inline Service Definitions] --> E
    E2[Analyze Service References] --> E
    E3[Remove Abstract Definitions] --> E

    F1[Check Circular References] --> F
    F2[Check Definition Validity] --> F

    G1[Remove Unused Services] --> G
    G2[Remove Private Aliases] --> G

    H1[Resolve Hot Path] --> H
    H2[Apply Final Optimizations] --> H

    style D fill:#e1f5fe
    style E fill:#f3e5f5
    style F fill:#fff3e0
    style G fill:#ffebee
    style H fill:#e8f5e8

TYPE_BEFORE_OPTIMIZATION (Blue): Where most custom compiler passes (like ProfilerPass) are typically registered. This is where services are analyzed and tagged services are processed.

TYPE_OPTIMIZE (Purple): Internal Symfony optimization passes that inline services and optimize the container structure.

TYPE_BEFORE_REMOVING (Orange): Validation passes that check for circular references and definition validity before cleanup.

TYPE_REMOVE (Red): Cleanup passes that remove unused services and private aliases.

TYPE_AFTER_REMOVING (Green): Final optimization passes after cleanup is complete.

Within each phase, compiler passes are executed in priority order (highest to lowest), allowing for fine-grained control over the execution sequence when multiple passes are registered in the same phase.

Autoconfiguration

Autoconfiguration is a powerful feature of the Drupal service container that allows services to be automatically tagged based on their class definitions.

When a service is defined in the container, the autoconfiguration process analyzes the class and applies the appropriate tags. For example, if a service implements a specific interface or extends a particular base class, the container can automatically apply the relevant tags to the service definition.

namespace Drupal\Core;

class CoreServiceProvider
    implements ServiceProviderInterface, ServiceModifierInterface {

    public function register(ContainerBuilder $container) {
        [...]
        $container
          ->registerForAutoconfiguration(EventSubscriberInterface::class)
          ->addTag('event_subscriber');
    }

    public function alter(ContainerBuilder $container): void {
        [...]
    }
}

In the example above, the CoreServiceProvider class registers an autoconfiguration rule that automatically tags any service implementing the EventSubscriberInterface with the event_subscriber tag. This means that when a service is defined that implements this interface, it will automatically receive the event_subscriber tag without needing to explicitly define it in the service definition.

Autoconfiguration is particularly useful for module developers, as it streamlines the process of registering services and ensures that they are properly configured without requiring extensive boilerplate code.

Since Drupal 10.2.0, several interfaces have been registered for autoconfiguration in CoreServiceProvider. At the time of writing (Drupal 11.3.0), those interfaces, and their corresponding tags, are:

• MediaLibraryOpenerInterface (tag: media_library.opener)
• EventSubscriberInterface (tag: event_subscriber)
• LoggerAwareInterface (tag: logger_aware)
• PreWarmableInterface (tag: cache_prewarmable)
• ModuleUninstallValidatorInterface (tag: module_install.uninstall_validator)

Of course, custom autoconfiguration rules can be added in any module’s service provider class, allowing for tailored service tagging based on specific module requirements:

namespace Drupal\sm;

final class SmServiceProvider implements ServiceProviderInterface {

  public function register(ContainerBuilder $container): void {
    $container->registerForAutoconfiguration(TransportFactoryInterface::class)
      ->addTag('messenger.transport_factory');
    $container->registerForAutoconfiguration(ServiceLocator::class)
      ->addTag('container.service_locator');
    }
}

Unfortunately, autoconfiguration only works for tags that doesn’t have attributes.

With all those concepts in place, we can remove some boilerplate from our service definition by going from a service definition like this:

webprofiler.profiler_listener:
  class: Drupal\webprofiler\EventListener\ProfilerListener
  arguments:
    - '@webprofiler.profiler'
    - '@request_stack'
    - '@webprofiler.matcher.exclude_path'
  tags:
    - { name: event_subscriber }

to this:

webprofiler.profiler_listener:
  class: Drupal\webprofiler\EventListener\ProfilerListener
  arguments:
    - '@webprofiler.profiler'
    - '@request_stack'
    - '@webprofiler.matcher.exclude_path'

assuming that the ProfilerListener class implements the EventSubscriberInterface, which is already registered for autoconfiguration in CoreServiceProvider.

In the next part of this series, we will explore aliases, autowiring, and named arguments, demonstrating how to resolve and inject dependencies based on type hints, reducing boilerplate code, enhancing maintainability, and going even further in simplifying service definitions by removing the arguments section entirely:

webprofiler.profiler_listener:
  class: Drupal\webprofiler\EventListener\ProfilerListener

Stay tuned!
